Merida eOne-Sixty SL 6000 2025

Merida’s eOne-Sixty SL is part of the new-wave of lightweight, powerful electric mountain bikes for riders who want the poise and ride feel of an unassisted bike.

Extremely fun to ride, High-quality components, Agile riding character, Intuitive handling – ebike-mtb.com

With 170 mm travel at the front and 174 mm at the rear, it’s perfectly at home on a race track or hitting the trails on repeat.

The award winning FAST kinematic suspension and Agilometer sizing of the regular One-Sixty enduro complement proven e-bike heritage. Low maintenance flexstay suspension offers size-tuned progression to maximise performance for all riders and it can be run with the latest coil shocks.

Flip chip design enables you to run with mixed size 29″ front and 27.5″ rear wheels as standard or switch to a focussed full 29er setup without compromising the geometry that’s been designed for the toughest enduro trails.

Thanks to a 30-230 mm travel-adjustable dropper post, you can choose between a longer frame for more stable handling or a shorter one for an agile feel – whichever suits you.

Features:

• Bosch Performance Line SX motor
• Bosch CompactTube (CPT) 400Wh battery
• Marzocchi Z1 160mm air fork
• Marzocchi Bomber Air shock
• Shimano Deore 12 speed transmission
• Shimano Deore 4 piston hydraulic disc brakes





Merida Sizing –

• X-Short: 145cm – 165cm
• Short: 155cm – 175cm
• Mid: 165cm – 185cm
• Long: 175cm – 195cm
• X-Long: 185cm+

Merida’s latest range of mountain bikes makes use of a slightly new approach to sizing. Merida encourage riders to consider their riding style when selecting a frame size.

For example the Mid size frame is suitable for riders of heights between 165-185cm. This means a rider of height 175cm could select a Short frame if the preference is agility, Mid for a balanced ride or Long for stability.



Specifications::eOne-Sixty SL 6000

• Discipline: Enduro/Trail

• Material: Carbon

• Front Travel: 160mm

• Rear Travel: 160mm

• Wheel Size: 29″

• Warranty: Lifetime (frame)

FRAME – eONE-SIXTY SL CF3 I ; carbon; 160mm travel; 29×2,4″ max. tyre size; 148x12mm bolt through axle; fixed battery

MOTOR – Bosch Performance Line SX

BATTERY – Bosch CompactTube (CPT); 400Wh

DISPLAY – Bosch Purion 400

MODE SWITCH – Bosch Mini Remote

SHOCK – Marzocchi Bomber Air

FORK – Marzocchi Z1 eMTB; Air; 160mm travel; Tapered; 44mm fork offset; 29×2.6″ max. tyre size

GEARS – 12

SHIFTERS – Shimano Deore

REAR DERAILLEUR – Shimano Deore

CHAIN – Shimano Deore M6100

CHAINSET – FSA 1x Alloy Spider + Mega Tooth steel chain ring; 34 teeth. FSA CK-220 wide E-Bike Forged Crankset; 165mm for all sizes

CASSETTE – Shimano Deore; 10-51 teeth; 12 speed

BRAKE LEVER – Shimano Deore

FRONT BRAKE – Shimano Deore 4 piston hydraulic disc caliper with Shimano RT64, 220mm rotor

REAR BRAKE – Shimano Deore 4 piston hydraulic disc caliper with Shimano RT64, 200mm rotor

GRIP – Merida Expert EC

HANDLEBAR – Merida Expert eTR; 780mm wide; XS,S 20mm rise ; M,L,XL 30mm rise

STEM – Merida Expert eTR II; aluminium; 35 DSH; 0 ASD; Supernova mount. 40 mm all sizes

HEADSET – Acros ICR Merida integrated neck with Blocklock

PEDALS – VP VP-532

SADDLE – Merida Comp SL; 28% recycled material; V-mount; incl. Merida minitool

SEATPOST – Fox Transfer Perforamnce Elite; 34,9mm diameter; 0 mm lay back;

RIMS – Merida Expert TR II; 28mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included); front 29″; rear 29″

SPOKES – Black stainless

FRONT HUB – Shimano TC500; 15x100mm; 32 spoke; Centerlock

REAR HUB – Shimano TC500; 12x148mm; 32 spoke; Centerlock with Merida Expert TR axle; including removeable lever, 6/4mm allen key

FRONT TYRE – Maxxis Assegai; 29×2.5″; kevlar bead; TR EXO+ 3C MaxxGrip

REAR TYRE – Maxxis Minion DHR II; 29×2.4″; kevlar bead; TR EXO+ 3C MaxxTerra

FRONT LIGHT – CG-119PG-BLACK(1)

REAR LIGHT – CG-404RG-BLK
