The Marlin+ is an optimal choice for riders seeking an introduction to electric mountain biking. Its trail-honed frame provides superior command, while the Bosch Active Line Plus motor supplies enough oomph to reduce the strain of extended climbs.
An Alpha Platinum Aluminium frame with proven mountain bike geometry and a 120 mm coil-sprung fork offers superior performance. The Bosch Active Line Plus 50 Nm drive and 18-speed Shimano CUES drivetrain allow you to reach speeds of 20mph/25kph with ease. Additionally, the Purion 200 remote with integrated display, and hydraulic disc brakes, provide reliable performance even under heavy load.
- Frame Alpha Platinum Aluminium, tapered head tube, internal routing, rack, mudguard and kickstand mount, UDH, Boost148, 12 mm thru axle
- *Fork
- Size: XS SR Suntour XCM 34, coil spring, preload, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm thru axle, 100 mm travel
- Size: S , M , L , XL SR Suntour XCM 34, coil spring, preload, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm thru axle, 120 mm travel
- Skewer rear Bontrager Switch thru-axle, removable lever
- Rim Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
- *Tyre
- Size: XS , S Bontrager XT3 Comp, wire bead, 30 tpi, 27.5×2.40″
- Size: M , L , XL Bontrager XT3 Comp, wire bead, 30 tpi, 29×2.40″
- Shifter Shimano U4000, 9-speed
- Rear derailleur Shimano CUES U4000
- Crank FSA CK-220, 165 mm length
- Chainring FSA, 32T, steel
- Cassette Shimano LINKGLIDE LG300, 11-46, 9-speed
- Chain Shimano LG500, 9/10/11-speed
- Pedal VP-536 nylon platform
- Saddle Bontrager Arvada, steel rails, 138 mm width
- *Seatpost
- Size: XS , S Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
- Size: M Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
- Size: L , XL Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
- *Handlebar
- Size: XS , S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
- Size: M , L , XL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
- Grips Bontrager XR Endurance Comp, lock-on
- *Stem
- Size: XS , S Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 35 mm length
- Size: M , L Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
- Size: XL Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
- Headset Semi-integrated, loose ball bearing, 1-1/8″ top, 1.5″ bottom
- Brake rotor Tektro, CentreLock, 203 mm
- Brakeset Tektro HD-M275 hydraulic disc
- Battery Bosch CompactTube 400 Wh
- Charger Bosch standard 2A, 230V, smart system
- Motor Bosch Active Line Plus
- Computer Bosch Purion 200
